CBCT Planning, The 3D Diagnostic Gate Every Implant Case Must Pass

Overview

Implant dentistry is not a freehand discipline. The difference between a thirty-year implant and a numb lower lip is often measured in single millimetres, the distance between a drill tip and the inferior alveolar nerve, the buccal plate, the sinus floor, the nasopalatine canal. Two-dimensional imaging cannot show you those millimetres. Cone beam computed tomography can.

For almost twenty years, panoramic and periapical radiographs were the baseline for implant planning. They remain useful for overview and screening. They are not sufficient when a titanium screw is going to be driven into a structure you cannot directly see. Nerves run in three dimensions. Bone resorbs in three dimensions. Sinuses pneumatise in three dimensions. Two-dimensional film flattens the problem and hides the risk.

Cone beam computed tomography, CBCT, was developed commercially in the late 1990s, with the first dedicated dental unit (the NewTom 9000) released in Italy in 1998 and the Imaging Sciences i-CAT launched shortly afterwards. It uses a cone-shaped x-ray beam that rotates once around the patient's head, capturing between 180 and 720 basis projections in a single scan of eight to forty seconds. A mathematical reconstruction assembles those projections into a volumetric dataset, a stack of voxels, each typically 0.1 to 0.4 millimetres on a side, that the clinician can slice, rotate, and measure in any plane.

This is not a shortcut. It is an engineered protocol backed by more than twenty years of clinical evidence, codified in position papers from the American Academy of Oral and Maxillofacial Radiology (AAOMR), the European Association for Osseointegration (EAO), and the SEDENTEXCT European consortium.

What Is CBCT?

Cone beam computed tomography is a three-dimensional radiographic imaging technique that captures volumetric data of the jaws, teeth, sinuses, and surrounding anatomy using a single, short, low-dose scan. It is not the same machine as the medical CT scanner used in hospital radiology. It is a smaller, upright, dental-specific unit engineered for the craniofacial region.

The Physical Principle

• A cone-shaped x-ray beam is emitted from a source on one side of the patient's head
• A flat panel detector on the opposite side captures the attenuation pattern as the x-rays pass through tissue
• The source and detector rotate 180 to 360 degrees around the patient in a single pass
• Between 180 and 720 individual two-dimensional projections (basis images) are acquired during the rotation
• A reconstruction algorithm, typically filtered back-projection or an iterative variant, assembles the basis images into a three-dimensional volume

The output is a dataset of voxels (volumetric pixels). Each voxel has a defined x, y, and z coordinate and a gray-value representing tissue density at that point. A dental CBCT volume typically contains 40 to 600 million voxels.

Voxel Resolution, Why 0.2mm Matters

The voxel dimension is the single most important specification of a CBCT scan. Most modern dental CBCT machines offer isotropic voxel sizes of 0.1mm, 0.125mm, 0.2mm, 0.25mm, 0.3mm, or 0.4mm, isotropic meaning the voxel is a cube with equal dimensions in every direction, so measurements are identical whether you slice axially, sagittally, or coronally.

For implant planning at Stunning Dentistry, the default protocol is 0.2mm voxel resolution on the i-CAT FLX. Below that, at 0.125mm or 0.1mm, the radiation dose rises appreciably without a diagnostically meaningful gain for most implant decisions. Above that, at 0.3mm or 0.4mm, the nerve canal outline blurs at high magnification, and measurement precision degrades below the two-millimetre buffer the International Team for Implantology (ITI) requires around the inferior alveolar nerve.

Field of View, Small, Medium, Large

CBCT units offer selectable field of view (FOV), the cylindrical region of anatomy captured in the scan:

• Small FOV: approximately 5 × 5 cm, single quadrant, single tooth, focused diagnostic question
• Medium FOV: approximately 10 × 10 cm, single arch or both arches, most implant cases
• Large FOV: 15 × 15 cm and larger, full skull, orthognathic surgery, airway analysis, bilateral zygomatic planning

Dose scales directly with FOV. A small-FOV scan on a modern unit delivers an effective dose of roughly 20 to 100 microsieverts; a full-skull large-FOV scan can reach 100 to 500 microsieverts depending on protocol, per the widely cited Ludlow 2008 dosimetry study and subsequent SEDENTEXCT data.

What CBCT Is Not

• It is not a medical CT scan, the dose is roughly one order of magnitude lower and the machine geometry is different
• It is not a replacement for panoramic imaging as a screening tool, panoramic remains appropriate for overview and orthodontic screening
• It is not a soft-tissue imaging modality, it shows bone, air, and tooth structure; it does not show muscle, nerve tissue itself, or tumour histology
• It is not a density-calibrated tool, its gray values are not interchangeable with Hounsfield Units on medical CT, per Pauwels 2013

Why Choose CBCT, The Clinical Case

When an implant case is being planned, the realistic imaging options are: periapical film, panoramic radiograph, CBCT, or medical CT. Each has clinical indications. Here is why, for the majority of implant cases, and for every full-arch case, every sinus-adjacent case, and every nerve-adjacent case, CBCT is the most defensible choice.

1. It Shows You the Nerve

The inferior alveolar nerve runs through the body of the mandible in a canal that is not reliably visible on panoramic imaging. Panoramic radiographs distort vertical measurements by 10 to 30 per cent depending on patient positioning and arch curvature. The mental foramen, where the nerve exits, has an anterior loop that extends a mean of three millimetres and up to seven millimetres beyond the radiographically obvious foramen edge. Drilling into that anterior loop produces permanent paraesthesia. CBCT shows the canal course, the cortical roof, and the loop in three planes.

2. It Measures Bone in the Plane That Matters

An implant is placed perpendicular to the occlusal table, not to the jawline. Panoramic height measurement is along the arch curve, not along the implant trajectory. CBCT reconstructs cross-sectional slices perpendicular to the intended implant axis, so the bone height and bone width measured on screen are the bone height and bone width the drill will actually encounter.

3. It Rules Out Sinus Pathology Before You Breach the Floor

Before any maxillary posterior implant or sinus lift, the sinus must be checked for pathology, mucosal thickening, polyps, retention cysts, opacification, septa. Panoramic imaging flattens the sinus into a two-dimensional shadow. CBCT shows the sinus in cross-section, identifies septa that would otherwise be perforated during a lateral window osteotomy, and confirms the membrane thickness before surgery. Roughly a third of patients presenting for posterior maxillary implants have a sinus finding that changes the surgical plan, per Pazera and colleagues.

4. It Lets You Place the Implant Virtually Before You Place It Physically

Once the volumetric dataset is in planning software (coDiagnostiX, Blue Sky Plan, NobelClinician/DTX Studio, RealGUIDE, Simplant), the planned implant, length, diameter, angulation, prosthetic emergence, is positioned virtually on the bone. Clearance to the inferior alveolar nerve, the mental foramen, the sinus floor, and adjacent roots is measured in millimetres. A restoratively driven position is verified against the intraoral scan. Only then is a surgical guide designed and milled.

5. It Catches Pathology You Did Not Come In For

The CBCT volume captures more than the implant site. Occult cysts, residual roots, impacted teeth, odontogenic tumours, internal resorption, calcified carotid atheromas, and airway narrowing all show up in the reconstructed volume. The AAOMR position paper explicitly recommends full-volume review by a trained reader precisely because the scan is a diagnostic opportunity, not only a planning tool.

6. It Generates the Surgical Guide

The DICOM volume merged with an STL intraoral scan is the input to guide design. The guide is a stent that slips over the remaining teeth or the bone surface during surgery and holds the drill in the exact planned position, depth, and angulation. The precision ceiling of the final implant position is the precision floor of the CBCT that fed the plan.

7. The Dose is Defensible

A small-FOV implant-site CBCT delivers approximately 20 to 100 microsieverts, a dose comparable to a trans-Pacific flight from Rome to Los Angeles (roughly 40 to 80 microsieverts of cosmic radiation). The clinical value delivered for that dose, nerve mapping, bone measurement, sinus assessment, pathology detection, guide generation, is not achievable with 2D imaging at any dose.

The 3D Planning Workflow, From Scan to Surgical Guide

CBCT is the start of the workflow, not the end of it. The full 3D planning pipeline has five discrete stages, each of which must be clean for the surgical outcome to be clean.

Stage 1, The Scan

• Patient positioned upright in the CBCT unit, head stabilised with chin rest, forehead strap, and bite block
• Selected FOV chosen to match the clinical question (see FOV section below)
• Voxel resolution set to 0.2mm for standard implant cases, 0.125mm when fine cortical detail is required
• Scan duration 8 to 20 seconds depending on protocol; the patient holds still and exhales gently
• Basis projection data acquired, volume reconstructed on the workstation in under two minutes

Stage 2, DICOM Export

• The reconstructed volume is exported as a DICOM (Digital Imaging and Communications in Medicine) dataset, the same file standard used by medical CT, MRI, and hospital PACS systems
• File size ranges from 150 MB for a small FOV to 2 GB for a full skull
• DICOM is non-proprietary, meaning the file opens in any compliant planning software, not locked to the scanner vendor

Stage 3, Intraoral Scan Fusion

• A separate intraoral scan of the teeth and soft tissue is captured on 3Shape TRIOS 5, iTero, Medit i700, or Primescan
• The intraoral scan is exported as an STL (stereolithography) mesh
• Planning software merges the DICOM and STL datasets using common anatomical landmarks (occlusal surfaces of adjacent teeth) as registration points
• The merged dataset shows bone underneath the tooth surface, which is the dataset an implant can be planned against

Stage 4, Virtual Implant Placement

• Implant library (Straumann BLT, Nobel Biocare Active, Osstem TS III, Dentsply Astra, Zimmer Biomet, full brand and length/diameter catalogue) is loaded into the software
• Candidate implants are placed virtually, guided by the prosthetic plan (emergence profile, screw access, restorative envelope)
• Distance to the inferior alveolar nerve, mental foramen, sinus floor, lingual concavity, and adjacent root apices is measured and logged
• Two-millimetre minimum clearance is enforced per ITI consensus for the inferior alveolar nerve, with 3mm enforced as the Stunning Dentistry internal standard for any distal mandibular placement
• Bone density at each planned implant site is assessed qualitatively (Lekholm & Zarb D1–D4) from the gray-value reconstruction

Stage 5, Surgical Guide Design and Export

• Once the plan is approved by the prosthodontist and the implantologist, a surgical guide is designed around the planned implant positions
• Guide can be tooth-supported (for partially dentate cases), bone-supported (for fully edentulous arches), or mucosa-supported
• Guide file is exported as an STL mesh
• Milled in PMMA or 3D-printed in surgical-grade resin (BioMed Amber on Formlabs or equivalent), sterilised, and on the surgical tray the morning of surgery

The precision of the final drilled implant osteotomy is a function of every stage above. Fail any one and the chain breaks.

Radiation Dose, Safety, and the ALARA Principle

ALARA, As Low As Reasonably Achievable, is the guiding principle of diagnostic imaging, codified by the International Commission on Radiological Protection (ICRP) and adopted by AAOMR, EAO, SEDENTEXCT, and the Royal Italian and New Zealand College of Radiologists. The principle is simple: the benefit of the imaging must outweigh the risk of the dose, and the protocol chosen must deliver the diagnostic answer at the lowest dose that will produce it.

Dose Figures in Microsieverts (µSv)

The Ludlow 2008 dosimetry paper, published in *Dentomaxillofacial Radiology*, is the foundational reference for these ranges and is still cited as the dose benchmark in current ICRP documentation. The SEDENTEXCT consortium has since validated and refined the figures across multiple vendor platforms.

The ALARA Protocol at Stunning Dentistry

• Justification: every CBCT request is written against a specific clinical question. "I want to see the nerve" is not a question. "I need to measure cortical clearance above the left inferior alveolar nerve for a 10mm implant at tooth 36" is a question.
• Optimisation: FOV is chosen to cover the anatomy that matters, not "everything just in case." A single posterior implant does not need a full-skull scan.
• Dose reduction: kV and mA are reduced for paediatric and small-adult patients per the manufacturer's pulsed-dose protocols. Our i-CAT FLX uses QuickScan+ pulsed acquisition where clinically appropriate.
• Shielding: thyroid collar on every patient. Lead apron on any scan below the lower border of the mandible.
• Pregnancy screening: all female patients of reproductive age are asked about possible pregnancy before the scan. A suspected pregnancy defers the scan to the appropriate window unless clinically urgent.

Internal Audit of Appropriateness, 2024 Data

In 2024 our clinical quality committee audited every CBCT taken across the Stunning Dentistry footprint against the SEDENTEXCT and AAOMR selection criteria. Of the scans audited, every single one had a documented justification, and 97 per cent fell within the dose range appropriate to the clinical question. The 3 per cent that exceeded the expected dose were almost entirely large-FOV zygomatic planning cases, where the bilateral full-maxilla scan is clinically mandatory. The audit is re-run every twelve months.

Clinical Equipment & Technology

A predictable case is only as good as the planning and fabrication stack behind it. The infrastructure below is what every Stunning Dentistry case runs through, from the first scan to the final torque check.

For the full equipment showcase including sterilisation, smile-design tooling, and the case-documentation registry, see Our Clinical Equipment & Technology.

Symptoms and Signs That Indicate You May Need CBCT

CBCT is rarely the first-contact diagnostic. A clinician orders CBCT when two-dimensional imaging, clinical examination, and history combine to surface a question that only 3D can answer. Here are the patterns that cross the threshold.

Planning and Structural Signs

• You are being assessed for any dental implant, full-arch or single
• You have been told you have "not enough bone" for an implant and want to verify
• You have a sinus lift, block graft, or ridge augmentation planned
• You have a failing root canal with suspected vertical root fracture
• You have an impacted wisdom tooth close to the inferior alveolar nerve
• You have an unerupted or ectopic tooth that needs localisation
• You have a TMJ complaint with suspected structural joint change
• You have been quoted zygomatic or pterygoid implants

Pathology and Incidental Signs

• A cyst or radiolucency of uncertain size or extent on panoramic
• A failed previous implant where the cause is not obvious on 2D film
• A suspected odontogenic tumour (ameloblastoma, odontogenic keratocyst, cementoblastoma)
• A fractured root tip or residual root not clearly localised on periapical
• A suspected fracture of the mandible, maxilla, or zygomatic process
• Calcifications in the neck region visible on panoramic (possible carotid atheroma, forwarded to GP)

Pre-Surgical Signs

• Any extraction near a vital structure
• Any orthognathic surgery planning
• Any temporary anchorage device (TAD) placement in thin-cortex regions
• Any revision case where a previous implant or graft has failed

When CBCT Is Not Indicated

• Simple caries diagnosis (bitewing or periapical is correct)
• Routine six-month hygiene review
• Uncomplicated single-root endodontic treatment
• Paediatric screening where panoramic suffices
• "Just because I am curious what my jaw looks like"

If three or more of the planning signs above apply to you, a CBCT is clinically appropriate. If none apply and you are being pushed toward a CBCT by a clinic that has not documented the question it will answer, that is a red flag in the opposite direction.

Who Is a Candidate?

Ideal Candidates

• Patients being assessed for dental implants at any site
• Patients with known or suspected complex anatomy
• Patients whose previous imaging has raised an unanswered question
• Patients undergoing full-arch rehabilitation, zygomatic implants, or graft procedures
• Patients in revision planning after a previous implant failure
• Patients undergoing any third molar surgery where the nerve canal is not clearly on one side of the root on panoramic

Relative Contraindications

• Pregnancy, CBCT is deferred unless the clinical urgency overrides the dose concern. Thyroid shielding and abdominal shielding are mandatory if proceeding. First-trimester pregnancy is the most cautious window.
• Inability to remain still for 10–20 seconds, paediatric patients, patients with movement disorders, patients with severe anxiety. Motion degrades image quality and may require a repeat scan.
• Metallic dental restorations in the direct FOV, large crowns, posts, orthodontic wires, and cast metal frameworks produce streak artefacts. These do not contraindicate the scan but warrant a discussion of expected image quality in the relevant region.
• Very large body habitus exceeding machine load ratings, a small minority of CBCT units have weight limits; a wider-bore machine or alternative protocol may be needed.

Medical Evaluation Before CBCT

No medical clearance is required for a standard dental CBCT in the overwhelming majority of cases. The dose is low, the scan is non-invasive, and no contrast agent is used. The clinical prerequisite is simply an honest medical history form (confirming pregnancy status, implanted electronic devices, and relevant prior imaging history) and a clinical justification signed by the referring clinician.

Consequences of Skipping CBCT Before Implant Surgery

The cost of skipping CBCT is not measured in dollars. It is measured in nerves, in sinuses, in implant failures, and in revision surgeries that would have been unnecessary if the three-dimensional question had been answered before the drill went in.

What Happens Without 3D Nerve Mapping

The inferior alveolar nerve runs through the body of the mandible from the lingula to the mental foramen. Its course is not a straight line. Published data shows the bucco-lingual position of the canal varies substantially across individuals, and the anterior loop of the mental nerve extends beyond the obvious foramen edge in roughly 60 per cent of patients:

• Mean anterior loop length: 3mm
• Maximum documented anterior loop length: 7mm
• Incidence of paraesthesia after posterior mandibular implant placed without CBCT: 1.3–8.5 per cent in published cohorts
• Incidence with CBCT-guided planning and a 2mm safety buffer: under 0.5 per cent

A numb lower lip or chin after implant surgery can be temporary, or permanent. The difference is measured in the preoperative scan.

What Happens Without 3D Sinus Assessment

• Unrecognised maxillary sinus septa are perforated during lateral window osteotomy in roughly 1 in 3 graft cases where pre-operative CBCT was not performed
• Mucosal pathology not seen on panoramic produces post-operative sinusitis
• Incorrect assessment of residual bone height leads to implant placement into the sinus cavity itself

What Happens Without Cortical and Concavity Mapping

• Lingual plate perforation in the posterior mandible during osteotomy, particularly over a deep submandibular fossa, can produce serious floor-of-mouth haemorrhage
• Buccal plate perforation in the anterior maxilla produces recession, thread exposure, and aesthetic compromise
• Nasopalatine canal encroachment in anterior maxillary placement compromises integration

What Happens at the Revision Stage

An implant placed too close to a vital structure may need to be removed, a bone-destructive procedure that compromises the site for future replacement. The total biological cost of a single avoidable misplacement can be 12 to 18 months of graft-and-wait before the site is restorable again.

What Happens to the Cost

• An implant misplacement revision costs roughly EUR 4,000 to 12,000 per site in Italy, including explantation, graft, and replacement
• A sinus perforation requiring ENT referral adds EUR 2,500 to 5,000 of additional medical management
• A nerve injury case that results in legal review is orders of magnitude higher

A EUR 180 CBCT scan prevents a EUR 12,000 revision. The arithmetic is not subtle.

Field of View Selection, Matching the Scan to the Case

The FOV dial is the most dose-consequential decision in CBCT. A clinician who reflexively uses the largest FOV "to capture everything" is exposing the patient to more radiation than the clinical question requires. Here is the selection protocol.

FOV Selection Table

Why Not Always Use the Large FOV?

A full-skull scan captures the thyroid gland, the salivary glands, the upper cervical spine, and the orbits within the imaged volume. These structures have radiosensitive tissue and have no contribution to most implant questions. Using a large FOV when a small FOV would suffice multiplies the dose to radiosensitive tissue by a factor of three to ten for no diagnostic gain.

Why Not Always Use the Smallest FOV?

Because some cases genuinely require the larger volume, bilateral zygomatic planning, bilateral posterior maxilla for All-on-6, any case where the contralateral reference is clinically needed. Under-sizing the FOV on a complex case forces a repeat scan, which doubles the dose. The FOV selection has to match the case, not a default.

Benefits of CBCT Planning, What You Get That 2D Imaging Cannot Deliver

The literature catalogues the diagnostic yield. Patients live with the surgical outcomes. Here is the lived difference, the set of things CBCT delivers that periapicals and panoramics cannot.

True Three-Dimensional Measurement

Every measurement taken on a CBCT is a true anatomical measurement in the plane the clinician selects. Panoramic magnification error of 10 to 30 per cent is eliminated. When a planning report states "13.2mm of bone height above the inferior alveolar nerve," that is 13.2mm of bone height, not a distorted estimate.

Nerve and Sinus Clearance Before the Drill

The single greatest benefit. The patient does not leave with a numb lip because the nerve position was known before the drill was selected.

Correct Implant Length and Diameter Selection

Choosing a 10mm implant because 10mm fits the visible panoramic height, when the true perpendicular bone height is 8mm, is the kind of error that 2D imaging routinely produces. CBCT shows the cross-sectional bone in the implant's own trajectory.

Virtual Try-Before-You-Cut

The virtual placement step allows the clinician to test multiple implant positions, diameters, and angulations against the anatomy and the prosthetic plan before committing. If a planned implant is 1.6mm from the mandibular canal in position A, a 2mm shift mesially recovers the buffer. That adjustment is made on the screen, not with a reoperation.

Surgical Guide Accuracy

Mean angular deviation of implants placed through a properly designed, CBCT-derived fully guided template is under 4 degrees; mean apical deviation is under 1.5mm, per multiple systematic reviews. Freehand placement without a guide commonly doubles those deviations.

Pathology Detection as a Byproduct

Incidental findings, carotid calcifications, airway obstruction, paranasal sinus pathology, cystic lesions, are identified in the same scan. Many of these findings trigger referrals that materially change a patient's general health trajectory.

Documentation for Long-Term Review

The DICOM volume is a permanent, reopenable three-dimensional record of the patient's anatomy on the day of planning. Ten years later, a new clinician can open the same file in current software and compare, bone levels, implant position, prosthetic emergence, against the intraoperative baseline.

Psychological Outcome, Visible Understanding

Patients who see their own CBCT on the screen, with the implant virtually placed, understand the surgery in a way no verbal description can reproduce. Informed consent is a stronger consent when the patient has seen the anatomy.

Scan Day Timeline, What Happens in the Chair

A structured view of what happens from walk-in to walk-out on a CBCT appointment at Stunning Dentistry.

Minute 0, Arrival and Check-In

• Reception confirms your referral, your medical history, and the clinical question the scan is being taken to answer
• Pregnancy screening question for female patients of reproductive age
• All metal removed from the head and neck, jewellery, removable dentures, hearing aids, hair clips

Minutes 5–10, Pre-Scan Briefing

• Imaging radiographer explains the sequence of events and the expected scan duration
• Patient positioned at the CBCT unit, standing or seated depending on model
• Thyroid collar fitted; lead apron applied if the thyroid is within or near the primary beam
• Bite block or chin rest engaged; forehead strap secured
• Laser positioning lines aligned with the occlusal plane and midline

Minutes 10–12, The Scan

• A final check: "Hold still, breathe gently through the nose, keep your eyes closed if that helps"
• The source and detector begin their single rotation
• 8 to 20 seconds of continuous acquisition depending on the protocol
• The image appears on the radiographer's workstation seconds after acquisition

Minutes 12–25, Reconstruction and Quality Check

• The workstation reconstructs the volume in roughly 60 to 120 seconds
• The radiographer inspects the volume for motion artefact, positioning error, and coverage of the anatomy of interest
• If the scan is clean, the patient is released
• If motion blur is present, roughly 1 in 80 scans, the decision to repeat is made at the machine, not at the planning review

Minutes 25–60, DICOM Export and Handoff

• The volume is exported in DICOM format
• Fused with the intraoral scan on the planning workstation
• Passed to the planning clinician for virtual implant placement at the scheduled review slot

Total Chair Time

• For a standalone CBCT: 15 to 25 minutes from arrival to departure
• For CBCT combined with intraoral scan and clinical examination on the same visit: 45 to 75 minutes

The scan itself, the part most patients worry about, is a small fraction of the appointment. The preparation and the positioning account for most of the time, and neither involves any radiation.

Artefacts, Limitations, and How They Are Managed

CBCT is not a perfect imaging modality. Honest planning requires honest acknowledgment of where the images can mislead and how the workflow mitigates those limitations.

Artefacts and Mitigation Table

What CBCT Cannot Do

• True quantitative density measurement. CBCT gray values drift across the volume and between scanners. A reading of "850 gray value" on an i-CAT is not the same as "850 gray value" on a NewTom. Use the scan for anatomy, not calibrated density.
• Soft-tissue differentiation. CBCT cannot tell a nerve from a small vein, a muscle from fat, or a benign cyst from a malignant tumour by image alone. Soft-tissue assessment remains the domain of MRI and biopsy.
• Dynamic or functional imaging. CBCT is a single static snapshot. It does not show jaw movement, airway collapse under sleep conditions, or blood flow.

The Artefact-Reduction Protocol at Stunning Dentistry

• i-CAT FLX metal artefact reduction algorithm enabled by default on any scan where a metallic restoration is in the primary beam
• Sub-volume acquisition offered when a dense restoration would dominate the full FOV
• Bite block and immobilisation mandatory on every scan, no exceptions
• Repeat-scan decision made at the machine by the imaging radiographer, not deferred to planning
• Supplementary periapical radiograph taken when the region of diagnostic interest is adjacent to a streak-producing restoration

CBCT vs Panoramic vs Medical CT

How to Read This Table

• Panoramic is your screening tool. For uncomplicated single-tooth questions, post-treatment monitoring, or generalised overview, it is still the right call at the right dose.
• CBCT is the standard of care for implant planning, full-arch reconstruction, and any case requiring three-dimensional bone or nerve assessment. It is not a replacement for panoramic, it is the next step when panoramic surfaces a question.
• Medical CT is reserved for cases where soft-tissue characterisation, emergency trauma assessment, or integration with broader hospital imaging is required. For routine implant planning, it delivers diagnostic parity with CBCT at roughly ten times the dose.

At Stunning Dentistry we use the ladder in sequence. A first-contact patient generally receives panoramic plus intraoral scan plus clinical examination. CBCT is added when the planning question requires it, which, for full-arch and posterior implant cases, is effectively always. Medical CT is referred to our partner hospital radiology only in rare cases, suspected malignancy, trauma, or pre-surgical planning for combined dental-maxillofacial surgery.

Patient Satisfaction and Diagnostic Confidence

The published literature on CBCT patient acceptance and diagnostic confidence is consistent.

• Patients shown their own CBCT volume report significantly higher confidence in the proposed treatment plan compared to those shown only 2D imaging, per multiple informed-consent studies including Mozzo and subsequent work
• Implant clinicians using CBCT-based planning report fewer intra-operative surprises, shorter operative times on complex cases, and measurably lower revision rates
• Patient-reported outcome measures (OHIP-14, implant-specific satisfaction scales) show higher scores in cohorts where planning was CBCT-led versus panoramic-led
• The diagnostic change rate, the proportion of cases where the treatment plan shifted after CBCT versus panoramic assessment, is reported at 19 to 38 per cent across studies, with the highest rate in posterior maxillary implant planning

Patients do not write reviews about their CBCT. They write reviews about the outcomes it protected, the lip sensation that was preserved, the sinus that was not perforated, the implant that is still there at year ten.

Patient Voices, Inline Stories from Italian Files

>, Helen, 64, Rome

>, Marc, 58, Milan

>, Joanne, 52, Naples

What Determines the Cost of CBCT?

Cost Variables

• Field of view: Small FOV is typically 30 to 60 per cent cheaper than large FOV at specialist radiology centres in Italy, reflecting both scan time and dose calibration
• Voxel resolution: Ultra-high-resolution (0.1mm) protocols are surcharged at some Italian centres
• Facility type: Hospital-based radiology is typically more expensive than standalone dental imaging centres; in-house dental clinic CBCT is usually the most affordable option
• Report type: A scan with a radiologist-written report is more expensive than an unreported scan
• Urgency: Same-day scans are surcharged at some Italian centres; scheduled scans are the baseline
• Repeat fee policy: Some Italian centres charge a full repeat fee for motion blur; others do not

What the Investment Reflects

• The CBCT hardware itself is a EUR 150,000 to 400,000 capital item, amortised across every scan
• The imaging radiographer is a trained professional, usually with dental radiography credentials
• The workstation, reconstruction software, DICOM viewer licensing, and PACS storage are ongoing costs
• Radiologist reporting (when provided) is a specialist medical fee
• Patient shielding consumables, maintenance, and calibration cycles are operational overheads

Published Italy vs India Cost Bands (Current as of April 2026)

We publish these bands rather than hide them. They are ranges, not quotes, your exact figure is finalised after consultation and clinical justification review.

What the EUR figure at Stunning Dentistry includes: scan on i-CAT FLX or Planmeca ProMax 3D, DICOM export on encrypted USB or secure transfer, in-house imaging board review, integration into planning software, virtual implant placement session, surgical guide design where indicated. No separate imaging invoice when CBCT is taken as part of an implant or full-arch package.

What the EUR figure in Italy typically reflects: private specialist radiology centre fees, imaging radiographer time, reporting dental radiologist or oral and maxillofacial radiologist fees, facility overhead, SSN (Servizio Sanitario Nazionale)-free item code (CBCT has no dental MBS item number in the overwhelming majority of cases). SSN (Servizio Sanitario Nazionale) does not rebate dental CBCT outside rare surgical indications under MBS item 58108. Private health extras may partially reimburse, typically EUR 30 to 150 per scan depending on policy.

Aftercare and Long-Term Image Stewardship

CBCT data does not age like a patient. The volume you are scanned on today remains diagnostically valid, and clinically useful for comparison, for as long as the imaging standard persists. Image stewardship is a long-term responsibility that begins the day the scan is taken.

Your Data Ownership Rights

• The DICOM volume is your medical record. You own a copy of it.
• At Stunning Dentistry, your DICOM is exported to an encrypted USB drive at the end of your treatment visit, and uploaded to our secure patient portal within 24 hours of the scan.
• If you wish the DICOM transferred to an Italian dentist, specialist radiologist, or second-opinion provider, we transfer it on written request via secure medical file transfer, no handling fee.

Storage Cadence

• Original DICOM retained on SD PACS for the minimum period required by Indian medical records regulations (currently 10 years), with SD policy extending indefinite storage for implant patients for the life of the implant
• Annual backup verification cycle
• Encrypted storage on two geographically separated servers

Re-Review Cadence for Implant Patients

• 6-month post-operative CBCT or panoramic for marginal bone level review
• 12-month post-operative CBCT for baseline long-term record
• Annual panoramic thereafter; CBCT only if a clinical question arises
• At year 5 and year 10, CBCT re-scan considered against a defined clinical question, not as routine

What Re-Review Looks Like

• Original plan opened alongside the new scan
• Implant position, integration, and marginal bone levels compared to baseline
• Prosthetic fit and framework passivity verified against the original design
• Any deviation from baseline flagged and managed clinically

Continuity-of-Care Annual Plan

The first year of aftercare is bundled into your treatment fee. From year 2 onwards, patients can opt into the Stunning Dentistry Continuity-of-Care Plan, an annual programme designed to make long-term review predictable rather than ad-hoc.

The plan is opt-in, opt-out annually, with no auto-renewal lock-in.

Responsibility Split, What You Do, What We Do

A CBCT planning protocol is a partnership. The clinical team takes the scan, reads the scan, and acts on the scan. You provide the honest information that allows the scan to be justified, taken safely, and interpreted correctly. Here is the responsibility map, written plainly.

What You Do (Before the Scan)

• Complete the medical history form honestly. Metallic implants, pacemakers, pregnancy status, recent imaging, allergies, all relevant.
• Disclose all previous imaging. If you have had a CBCT in Italy within the last 12 months, tell us. We may not need to repeat it.
• Remove metal before the scan. Jewellery, removable dentures, hearing aids, hair clips, glasses, anything in the FOV.
• Hold still during the acquisition. Eight to twenty seconds of immobility. Close your eyes if that helps.
• Ask questions when you see your own volume. You cannot consent to a plan you do not understand.

What We Do (Clinical, At the Chair)

• Justify the scan in writing. The clinical question, the referring clinician, the selected FOV.
• Shield correctly. Thyroid collar on every scan. Lead apron when appropriate.
• Use the lowest dose that answers the question. FOV matched to anatomy, pulsed protocol where possible, voxel resolution matched to the clinical need.
• Quality-check the volume before you leave. Motion artefact, positioning, coverage, verified at the machine.
• Read the full volume, not only the implant site. Incidental pathology is reported.
• Review the plan with you. The screen is turned toward you. Anatomy is explained. Questions are answered.
• Enforce clearance buffers. 2mm minimum to nerve; 3mm internal standard for distal mandibular placements per Dr. Priyank Sethi.
• Release the DICOM to you. It is your record.

Why This Split Matters

The scan cannot be justified if the medical history is incomplete. The dose cannot be optimised if the clinical question is unclear. The volume cannot be interpreted safely if the patient moved during acquisition. The plan cannot be consented to if the patient was not shown their own anatomy. Every step in the chain has a failure mode that is invisible until later, when the wrong implant is placed or the wrong structure is missed.

At Stunning Dentistry, we do not ask you to be a radiographer. We ask you to be an honest, engaged partner for the portion of the workflow that only you can control. We handle everything else.

Myths vs Clinical Reality

People Also Ask

Short, direct answers to the questions search engines consistently surface for CBCT planning. If you want depth, the full FAQ is below.

Does CBCT replace my panoramic X-ray?

No. CBCT supplements panoramic in specific 3D planning situations. Panoramic remains the first-line screening tool and is still indicated for overview, orthodontic assessment, and routine implant follow-up.

Can I reuse my Italian CBCT in India?

Yes, if the scan is in DICOM format, less than 12 months old, and covers the relevant anatomy. We review it first and only repeat if clinically justified.

How much radiation is a CBCT compared to a flight?

A small-FOV dental CBCT delivers approximately 20 to 100 microsieverts. A trans-Pacific flight from Rome to Los Angeles delivers 40 to 80 microsieverts of cosmic radiation. They are in the same order of magnitude.

What field of view does my case need?

Single implant: small FOV (5 × 5 cm). Full arch: medium FOV (10 × 10 cm). Zygomatic: large FOV (15 × 15 cm). Your specific case is matched at the planning review.

Is CBCT safe during pregnancy?

CBCT is deferred during pregnancy unless clinically urgent. If proceeding is necessary, thyroid and abdominal shielding is mandatory. First-trimester cases are handled most cautiously.

How long does the scan take?

The acquisition itself is 8 to 20 seconds. Total chair time including positioning, shielding, and quality check is 15 to 25 minutes.

Will I feel anything during the scan?

No. CBCT is completely painless and non-contact. You stand or sit still, the machine rotates around you once, and the scan is complete.

Does SSN (Servizio Sanitario Nazionale) cover CBCT in Australia?

In the overwhelming majority of dental indications, no. A narrow subset of surgical referrals attract partial rebate under MBS item 58108. Private health extras may reimburse EUR 30 to 150 per scan depending on policy.

CBCT Planning at Stunning Dentistry

Clinical Infrastructure

• i-CAT FLX units at every full-arch surgical location, with Planmeca ProMax 3D available for low-dose paediatric and motion-prone cases
• In-house CAD/CAM and 3D printing laboratory, complete digital workflow from CBCT scan to surgical guide to final prosthesis, with no external lab dependency
• Hospital-grade sterilisation: over 90 per cent single-use materials, HEPA air purification, multi-layer sterilisation protocols

Lead Clinicians On Your Case

The named bench you are paired with on day one of diagnosis:

• Lead Prosthodontist, owns the prosthetic plan, the digital articulator mount, the definitive material choice, and the year-1 occlusal review. Signs every case decision.
• Lead Implantologist, owns the surgical plan, the CBCT review, the insertion-torque + ISQ readings, and the immediate-loading decision.
• Periodontist, owns the soft-tissue assessment, peri-implant maintenance protocol, and any flap surgery.
• Maxillofacial Surgeon (zygomatic / advanced atrophy cases only), owns the anatomical planning, GA decision, and intra-op nerve mapping.

For the full specialist bench, including who is on call after you fly home, see Our Specialist Team.

Clinical Governance

• Every CBCT is justified against a written clinical question, co-signed by the referring clinician and the imaging lead
• Every implant planning review is a two-clinician minimum, treating prosthodontist plus implantologist, with Dr. Priyank Sethi personally reviewing any case within 3mm of a vital structure
• SEDENTEXCT and AAOMR selection criteria are the benchmark for appropriateness
• Internal quality committee audits the CBCT request register annually against those criteria; the 2024 audit confirmed 100 per cent documented justification and 97 per cent appropriate dose-per-question
• Registered with Dental Council of India + state council; specialist clinicians on national + provincial council specialist lists; <!-- AAID/AACD/AAO/BACD: VERIFY before publish -->
• <!-- BRAND DECISION GATE per FINAL-HANDOVER-MAP S5: Forbes claim wording requires brand sign-off. -->

Credentials & Recognitions

What we publish about credentials is what we can document:

• Founder credentials, Dr. Priyank Sethi: BDS, MDS Conservative Dentistry & Micro Endodontics (Peoples College), PhD Dental Sciences, Internationally Certified Digital Smile Designer, advanced training in DSD + Full Mouth Rehabilitation in Germany. Multiple peer-reviewed publications in national and international dental journals.
• Council registration, Registered with Dental Council of India + state council; specialist clinicians on national + provincial council specialist lists.
• Implant-system certifications, Nobel Biocare-certified provider, Straumann-certified provider, with manufacturer-training documentation on file.
• Software certifications, coDiagnostiX-trained, NobelGuide-trained, Internationally Certified Digital Smile Designer (DSD App workflow).
• International patient reach, verified 1000+ international patients across multiple regions.
• <!-- BRAND DECISION GATE per FINAL-HANDOVER-MAP S5: Forbes claim wording (e.g. "Forbes #1 / Ranked No. 1") requires brand sign-off. Until approved, do NOT publish that wording on this page. -->

For the full credentials documentation, see Awards & Recognition.

Safety & Sterilisation Standards

Every case at Stunning Dentistry runs through the same audited safety chain:

• Pre-op screening, medical history, anticoagulation review, HbA1c check (target ≤ 7.0 for elective surgery), bisphosphonate exposure, smoking-status protocol, fitness-to-fly clearance for international patients.
• Intra-op monitoring, sedation by registered anaesthetist when indicated, continuous SpO₂ + BP + ECG, surgical-pause checklist before fixture seating, instrument-count verification.
• Sterilisation suite, ISO-rated autoclaves, batch-tracked instrument trays, sterile drape protocol, surgical-grade water filtration to operatories, instrument single-use where indicated.
• Post-op infection monitoring, named protocol for swelling, discharge, fever; suture-line check at days 1 / 3 / 7 with photographic record.
• Fly-back warranty trigger criteria, named conditions that bring you back at SD's cost during the warranty window; written into the warranty document at delivery.
• Patient safety framework, the "Reject Clinic / Safe Clinic" red-flag matrix on our brand-promise / clinical-standards page so patients can audit any clinic.

The Commitment

• CBCT included in the first-visit implant consult package, no separate imaging invoice
• DICOM data released to the patient on encrypted USB at the end of the visit
• Repeat CBCTs during treatment, if clinically required, taken at no additional charge
• 100 per cent painless protocols with conscious sedation (for the surgical phase, not the scan)
• 24/7/365 dedicated CRM support
• International patient services: visa guidance, flight coordination, premium hotel arrangements, airport transfers, optimised scheduling

For Italian Patients: Your Journey to India

We have built a structured pathway for Italian patients, not an improvisation. For CBCT-led implant planning, the scan is Day 1 of your treatment and it gates every subsequent decision, from whether surgery proceeds, to which implant system is used, to whether a graft is required. The clinical protocol is identical to what you would receive in Rome, Milan, Turin, or Naples. What changes is the cost, the specialist depth, and the in-house digital infrastructure.

The Day 1 Protocol, CBCT as the Gate

Arrival and diagnostic workup (Day 1 at SD)

• Airport pick-up by CRM-arranged driver
• Hotel check-in
• Arrival at clinic for CBCT, intraoral scan, photographs, medical clearance, full prosthodontic consultation
• Scan taken on i-CAT FLX at 0.2mm voxel resolution, small or medium FOV as clinically indicated
• DICOM reconstructed and reviewed within the same clinical session
• Two-clinician planning review begins on Day 2

Treatment planning decision (Day 2 at SD)

• Prosthodontist and implantologist review the CBCT volume
• Nerve clearance, sinus floor, bone volume, and density assessed
• Virtual implant placement in coDiagnostiX
• Treatment plan presented to patient with screen visible, the plan is consented against the visualised anatomy
• Surgical guide designed and queued for printing

Downstream gating

• If the scan shows adequate bone and clear nerve pathway, immediate-load All-on-4 or All-on-6 proceeds
• If bone volume is compromised, zygomatic or pterygoid ladder is activated
• If pathology is identified, treatment is paused and the finding is managed first
• If the scan identifies a systemic concern, you are referred to your Italian GP with a written letter

The Two-Visit Model

Visit 1, Diagnostics, Surgery, and Provisional (7–10 days in India)

• CBCT, intraoral scanning, photographs, full diagnostic workup on arrival day
• Surgical planning meeting with prosthodontist and implantologist on Day 2
• Surgery day typically Day 3 or Day 4
• Recovery monitoring at days 1, 3, and 7
• Discharge home with provisional teeth, written aftercare protocol, DICOM on USB, and your CRM contact

Visit 2, Definitive Prosthesis (5–7 days in India, 4–6 months later)

• Follow-up CBCT where clinically indicated (bone level verification prior to final prosthesis), included at no additional charge
• New impressions and digital scans for the final prosthesis
• Try-in, final delivery, occlusal balancing, night-guard fitting
• Discharge home with the definitive prosthesis and warranty documentation

What We Coordinate For You

• e-Visa guidance for the Indian medical visa (typically issued within 72 hours of application)
• Flight booking assistance (we are not a travel agent, we direct you to vetted partners)
• Hotel partnership rates within 10–20 minutes of the clinic
• Airport pick-up and drop-off included
• A dedicated CRM manager assigned before your first booking, available 24/7/365
• DICOM transfer to your Italian dentist on request, secure, no handling fee

Companion Travel

We strongly recommend a travelling companion for the surgery visit. Companion accommodation is the same hotel; companion airport transfers are included.

What This Costs in EUR, Your Out-of-Pocket Reality

Here is the full out-of-pocket figure for an Italian patient where CBCT planning is the entry point to treatment, not just the scan fee, the total.

Standalone CBCT Only (No Surgery), Total EUR Cost

CBCT as Part of Full-Arch Implant Planning, Total EUR Cost (Single Arch)

Flexible Payment Pathways

The total figure above does not need to be paid upfront. Most Italian patients use one of three structured pathways:

Insurance-claim guidance: every line item on your Stunning Dentistry invoice is formatted to align with UniSalute / FASI / MetaSalute / Generali / Allianz Care claim codes. SSN (Servizio Sanitario Nazionale) typically does not cover adult full-arch implant rehabilitation. Your CRM coordinator pre-flags claim-eligible items before discharge so your private cover can absorb a portion of the total where eligible.

Stunning Dentistry does not earn commission from any financing partner. We surface the options so you can compare them against your own bank's medical-loan rate and pick the lowest-cost path.

What Insurance and SSN (Servizio Sanitario Nazionale) Cover for CBCT in Australia

• SSN (Servizio Sanitario Nazionale): Does not cover dental CBCT in the overwhelming majority of cases. MBS item 58108 applies only to narrow surgical pathology indications.
• Private health extras (Italian private cover): Typically reimburses EUR 30 to 150 per scan depending on policy. Marginal against the actual scan fee, and usually absent entirely when the scan is part of an implant package.
• At Stunning Dentistry: Detailed itemised invoices issued for every line of treatment including the CBCT component, suitable for private health claim submission upon return to Italy.

Is This Worth Flying For? The Italy vs India Decision Framework

Travelling for implant work that starts with a CBCT is a decision that hinges on what the scan will enable. Here is the framework we ask Italian patients to apply, honestly, with no pressure from us.

When India Is Clearly the Right Call

• Your total Italian implant quote is EUR 25,000+ per arch and your savings exceed EUR 8,000 after all travel costs
• Your case complexity requires integrated CBCT-to-surgery planning in one building (full arch, zygomatic, revision cases)
• You are medically fit for international travel
• You can take 2–3 weeks total off across two trips spaced 4–6 months apart
• You want access to in-house CBCT, CAD/CAM, 3D printing, and a full-time prosthodontist on every case, without paying Rome CBD rates

When India Is Not the Right Call

• A single-tooth posterior implant in well-visualised bone where the Italian price differential is modest
• Active health issues that contraindicate international travel
• You cannot commit to remote follow-up between visits
• You already have an existing Italian CBCT less than 12 months old and an Italian specialist relationship you do not want to interrupt
• The savings, after honest accounting, do not exceed EUR 5,000

When to Get a Second Opinion First

• A clinic in Italy or India has quoted implant placement without CBCT or without showing you the virtual plan
• A clinic has quoted CBCT at a price that includes nothing downstream, be clear whether you are paying for a scan or paying for a clinical decision
• You have not seen your own CBCT, the implant brand, or the written warranty
• A clinic is pressuring you to commit on the day of consultation

We will give you a free CBCT-based remote opinion before you commit to flying. If the right answer is to stay in Italy, we will say so. If your existing Italian CBCT is sufficient for the decision, we will say that too.

Your Time in India, Week-by-Week Schedule

A real schedule for a real trip, framed around CBCT as the clinical gate on Day 1.

Visit 1, Diagnostics, Surgery, and Provisional (10 days)

Between Visits, At Home in Italy (4–6 months)

• Weekly hygiene photo upload to clinical portal during month 1
• Bi-weekly Zoom check-in with your assigned prosthodontist for the first 8 weeks
• Monthly Zoom check-ins thereafter
• Local dental hygienist visit recommended at month 3 (we provide referral letter)
• Direct CRM access for any concern, response within 4 hours business, 24 hours overnight

Visit 2, Definitive Prosthesis (7 days)

Back in Italy, Your Follow-Up Plan

The CBCT you were scanned on during Visit 1 is the baseline against which every subsequent image is compared. Here is exactly how we maintain clinical oversight, and imaging oversight, from across the ocean.

Year 1, The High-Vigilance Year

Year 2 Onwards

• Annual remote review by Zoom, clinical photos, hygiene photos, radiograph upload
• Annual in-Italy hygienist visit
• CBCT re-scan only if a clinical question arises, not as routine
• Optional in-person review at Stunning Dentistry every 2–3 years
• Lifetime warranty active throughout

Imaging Stewardship Over the Life of the Implant

• Your original Day 1 DICOM remains the baseline
• Any subsequent CBCT, panoramic, or periapical is compared against that baseline
• Image portability: if you move cities or providers, the DICOM transfers with you
• Image retention: indefinite, per SD policy for implant patients

What "Remote" Actually Means for Imaging

The Zoom follow-up is not a substitute for imaging, it is a structured complement. When imaging is clinically required, you either upload a panoramic taken in Italy (we cover the cost and review the image the same week), or you schedule a trip for a Stunning Dentistry CBCT re-scan. Remote review handles pattern recognition; in-person imaging handles anatomical decisions.

If Something Goes Wrong After You're Home

We will be honest: no implant is risk-free, and the CBCT workflow does not eliminate risk, it reduces it. Here is the protocol for when something does go wrong.

Step 1, Contact Your CRM Manager Immediately

• Single point of contact, 24/7/365
• Phone, email, or WhatsApp
• Average response time: under 30 minutes during business hours, under 4 hours overnight

Step 2, Triage Within 24 Hours

• Same-day Zoom consultation with your prosthodontist
• Photo and intraoral video review
• Request for Italian panoramic or CBCT if imaging is indicated, we cover the cost per warranty terms

Step 3, Escalation Pathway

• Routine issues (loose component, hygiene concern): managed remotely, addressed at next planned visit
• Urgent issues (persistent pain, suspected peri-implantitis, screw failure): referral to a vetted Italian dentist for in-person assessment, with all clinical records and original DICOM shared; the visit is reimbursable under warranty terms
• Imaging-required issues (suspected nerve involvement, graft failure, implant position concern): Italian CBCT arranged at your nearest centre with the DICOM returned to Stunning Dentistry for comparative review against your baseline
• Emergencies (acute infection, major prosthetic fracture, suspected implant failure): immediate in-person assessment in Italy, expedited return travel for definitive management at Stunning Dentistry, flights and accommodation supported per the warranty schedule

Warranty Coverage in Plain Language

• Implants: lifetime warranty against failure to integrate or premature loss
• Prosthesis: documented warranty period covering material defects and structural failure
• Follow-up imaging: CBCTs arranged under the warranty terms are covered
• Repair fees: waived under warranty terms
• Documentation: every patient receives a written warranty document at definitive prosthesis delivery

We do not promise nothing will ever go wrong. We do promise there is a clear, written, structured response if it does, and that your original CBCT is the baseline every response is measured against.

Your Dental Tourism Safety Framework, Red Flags to Reject

If you are travelling for dental work, whether to us or to anyone else, these are the CBCT-specific warnings to take seriously.

Reject Any Clinic That:

• Offers to place an implant without a pre-operative CBCT (outside a narrow, documented subset of simple anterior cases)
• Refuses to show you the CBCT on screen before surgery
• Will not release your DICOM file on request
• Uses CBCT with no documented clinical justification written against each scan
• Cannot tell you the specific voxel resolution, FOV, or effective dose of the protocol they are running
• Reports "bone density in Hounsfield Units" from a CBCT (a clinical literacy red flag)
• Has no ALARA protocol or cannot explain dose optimisation
• Does not perform a full-volume read (site-only reads miss incidental pathology)
• Outsources CBCT to a distant radiology centre with no integrated planning workflow
• Has no in-house CBCT, no in-house CAD/CAM, no in-house surgical guide printing, and outsources the entire chain
• Charges you a "release fee" to give you your own DICOM file

What a Safe Clinic Looks Like:

• Written justification for every CBCT, co-signed by the referring clinician
• Transparent FOV selection protocol matched to case type
• Voxel resolution explicitly named in protocol documentation
• Effective dose published or available on request
• DICOM release to the patient on request, no handling fee
• Two-clinician planning review minimum
• Full-volume read, not site-only
• SEDENTEXCT or AAOMR selection criteria cited as the basis for appropriateness
• Willingness to decline a scan when the question can be answered with a lower-dose modality

If a clinic, including ours, fails any of the safety checks above, walk away. The CBCT is your anatomy, your dose, your record. You are the principal, not the patient file.

Partner Dentists in Italy, Our Network Roadmap

Honesty first: as of April 2026, our in-Italy partner network is in active expansion, particularly around imaging support.

What Is Live Today

• DICOM transfer protocol: secure, encrypted transfer of CBCT volumes between Stunning Dentistry and Italian providers, operational today for any Italian dentist or radiologist nominated by the patient.
• Remote CBCT review: a Stunning Dentistry specialist can open an Italian-taken DICOM, review it against a restoratively driven plan, and return a written second opinion, operational today.
• Italian hygienist roster: vetted hygienists in Rome, Milan, Turin, Naples, and Florence who provide local maintenance visits with full clinical records sharing.
• Emergency referral pathway: confirmed referral relationships with select Italian implant specialists for urgent in-person assessment under our warranty terms.

What Is Building Through 2026

• Formal partner-clinic agreements in Rome, Milan, Turin, and Naples, clinics where in-person CBCT review, image capture, and routine maintenance can happen as part of an integrated pathway
• Annual in-Italy clinical day visits by a Stunning Dentistry prosthodontist, on a rotating basis, for planning reviews and prospective consultations
• A published partner-clinic directory with credentials, scope of supported services, and patient feedback

What This Means for You

If you choose Stunning Dentistry today, you have:

• CBCT support from Day 1 through year 10+
• A DICOM file you own, portable across providers and geographies
• A structured remote follow-up that works
• A clear emergency pathway in Italy if something goes wrong
• A network roadmap that expands the in-person Italian imaging touchpoints throughout the year you are under our care

We will not oversell what does not yet exist. The remote imaging and planning workflow is excellent. The in-person Italian footprint is growing.

Clinics Near You, Which Stunning Dentistry Location Fits Your Trip

Stunning Dentistry operates from India's largest dental hospital footprint, with CBCT-equipped planning infrastructure at every surgical-capable location.

Our CBCT-Equipped Locations for Implant Planning

What Is the Same Across Every Location

• i-CAT FLX primary CBCT unit with identical acquisition protocol
• 0.2mm voxel resolution default, same FOV selection table, same ALARA protocol
• Identical coDiagnostiX and Blue Sky Plan planning stack
• Same Straumann, Nobel Biocare, and Osstem implant libraries
• Same two-clinician planning review
• Same lifetime warranty
• Same 24/7 CRM support pathway

What Differs

• Volume of international patient programs (Hyderabad runs the largest by volume)
• Availability of the Planmeca ProMax 3D Max secondary unit (Hyderabad flagship only)
• Adjacent travel/recovery options

How We Help You Choose

Once you book your initial consultation, your CRM manager will recommend the location best matched to your case complexity, your flight preferences, and your travel dates. There is no difference in imaging quality across our locations, the hardware, the protocol, and the clinical review are uniform by design.
